5-8
5-7. Table of default internal data values
Item Default value
Tag number XXXXXXXX
Output format ANALOG XMTR
Burnout direction DOWN SCALE
Actuator operation REVERSE
Positioner operation DIRECT
Valve operation DIRECT
Actuator size PARAM 1
Hysteresis HEAVY
PID parameters
(parameter 0)
P 1.200
I 4.000
D 0.5000
GE +/-0.000%
GP 0.7000
GI 4.000
GD 0.5000
Flow characteristics LINEAR
User defined flow characteristics data
(Pressure balance type adjustment valve
(ADVB/ADVM) linear characteristics data)
Valve fully closed value (LRV) 4.000mA
Valve fully open value (URV) 20.00mA
Forced fully closed input value 0.5000%IIN
Forced fully open input value 109.00%IIN
Digital output
settings
Output signal mode Single Range
Amount of data mode DE-4Byte
Failsafe mode F/S=B/O Hi
