Aztech HL117EW User Manual

User Manual
Page 7 of 40
Simple
Connect
Button
Press to create or join a HomePlugAV network.
 When Simple Connect is pressed for more than 10 seconds, it
will randomize the Private Network Name.
 Then Press for 2 seconds to pair the device.
Dual Band
Switch
This allows you to manually switch to either 2.4 Ghz or 5 Ghz
frequency band.
Device LED Behaviours
Label
Status
Description/ Function
Power LED
OFF
 No power.
ON
 HomePlugAV is on a Power Saving Status if the Power
LED is blinking slowly.
 When the Simple Connect button is pressed for ten
(10) seconds, this LED will turn OFF and turn ON to
confirm the Private Network Name reset.
 After the Simple Connect button is pressed for two (2)
seconds, this LED will blink to confirm the button press.
 If the Reset Button is pressed for three (3) seconds, this
LED will also turn OFF and turn ON.
Powerline
Activity
OFF
Device is not connected to a HomePlugAV network.
ON
 When the Simple Connect is pressed for ten (10)
seconds, this LED will turn OFF to confirm the Private
Network Name reset.
 This LED is steady in color when the device is part of a
HomePlugAV network.
 The LED colors represent the current connection rate
within the HomePlugAV network; whether it is good
(red), better (amber), or best (green).
Ethernet
Activity
LEDs
1 & 2
OFF
An Ethernet device is connected to the corresponding port.
ON
 The corresponding LED is steady when an Ethernet
device is connected.
 When Simple Connect is pressed for ten (10) seconds,
this LED will turn OFF and turn ON to confirm the Private
Network Name reset. (Ethernet is connected)
 The LED flashes to indicate Ethernet activity.
