General Description
© b2 electronic GmbH DHV0088 34
Nr. Picture Name Description
Earth Connection Discharge Stick Earth connection for Discharge Stick
Discharge Stick Tip of Discharge Stick, resistors in serial to discharge energy
Discharge Stick Hook of discharge for grounding (earthing) – direct short
PD impedance 3,9kOhm; MC
male - MC female
Additional PD Filter (from accessories)
