4 Design and Construction
© b2electronic gmbh
DHV0053 b2 EN
Data Transfer Modes
The HVA28TD built in memory can save up to 100 reports and 80 test
sequences. Data storage location and transfer capability depends on the
configuration of the communication port (13).
Configuration
Characteristics
USB
• During testing, put the USB Flash Drive into the communication port
(13)
• When connected, left hand corner of main menu displays “USB”
enabled (green).
• Test sequences are directly saved to HVA28TD memory
• New reports are directly saved to USB stick inserted
• All reports saved in HVA28TD memory, can be transferred to the
linked USB stick:
• During testing, USB adapter and stick are connected to
communication port (13)
• When connected, left hand corner of main menu displays “USB”.
• Test sequences are directly saved to HVA28TD memory
• New reports are directly saved to USB stick inserted
• Reports saved on the USB stick can be retrieved and viewed on the
HVA28TD display.
• All reports saved in HVA28TD memory, can be transferred to the
linked USB stick:
