PCA
Technical Characteristics
Power Requirements:
Four AA alkaline batteries. Battery backup for the real-time clock, RAM,
and bias voltage for the Nitric Oxide sensor is provided by internal
lithium
batteries. Optional AC Power Supplies (110 VAC & 230
VAC) are also
available.
Operating Time:
A fresh set of batteries will provide at least 8
hours of continuous opera-
tion with the pump running and the backlight turned on.
Warm Up Time:
60 seconds.
Printer Interface:
Infrared Communications (refer to Section 4.24).
Materials:
•
High impact ABS plastic case
•
Polycarbonate window over the display
•
Nickel plated, brass quick-connect hose fitting
•
Stainless steel probe
Dimensions:
Height:
.................. 8.5
in. (215 mm)
Width:
...................
3.8 in.
(96 mm) at display (3.0 in. [75 mm] at controls)
Depth:
................... 2
in. (50 mm)
Weight:
With
Batteries:
.....
Approximately 1.5 lbs (0.7 Kg)
Instruction 0024-9219
2-3
