PCA
4.13 Temperature Setup Screen
SETUP
TEMPERATURE UNIT «°C
°
F
Operation
The Temperature Setup Screen is displayed by repeatedly pressing the
MENU
key from the Combustion Test Screen. Use this screen to setup the
analyzer to display temperature in either °C or °F.
To select the temperature unit-of-measure, first use
the
st
keys to move
the cursor (
z
) in front of
°C
or
°F
, and then press the
ENTER
key.
Front Panel Key Functions:
–
Move cursor
(
z
) up
–
Move cursor
(
z
) down
–
Select unit-of-measure next to cursor
–
Go to Combustion Test Screen
– Go to
Draft Unit Setup Screen for PCAs with a pressure
sensor, or the O
2
Reference Screen for ‘Advanced’ PCAs that
have an NX and/or CO sensor, or the Language Setup Screen
for all other PCAs
Instruction 0024-9219
4-19
