6
-
19
MAINTENANCE
6
► ADJUSTING
If not, loosen nuts at the end of the
cylinder rod on both sides and adjust
the length of the screws. Tighten the
nuts when the toe-in is 0.16~0.3 in
(4~8 mm).
Left and right adjustment of screw
length must be same.
(1) Tie Rod Nut (2) Cylinder Rod
2
1
FUSE & FUSIBLE LINKS
(1) Fusible Links
Stop the engine and check the main
fuse. (Fusible link)
Open the fuse box cover and check
the fuses. Replace any burnt-out fuses
with new ones of required capacity.
A fusible link is a type of fuse, which
burns and disconnects the current in
the event of excessive current owing
in the circuit , if plastic coating is dis-
colored when it is cut o , it should be
inspected by a authorized dealer.
•
When replacing the fuse, use
only the one of the same ca-
pacity.
WARNING
If the fuse burns immediately after
being replaced, it must be checked
by the authorized dealer.
