BAD BOY TRACTOR
CLUTCH PEDAL
If the clutch pedal is depressed, driv-
ing power is stopped supplying.
When the clutch pedal is depressed,
the main/range shift lever can be op-
erated. To start o󰀨 smoothly, release
the clutch pedal slowly.
(1) Clutch Pedal
BRAKE PEDAL
Brake pedals are independent of
each other and can be used for mak-
ing a small turn on the pavement.
Depressing the brake pedal on the
side to which to make a turn, the rear
wheel on that side is stopped and the
tractor can make a small turn.
(1) Brake Pedal
WARNING

Make sure to interlock the left
and right brake pedals with
the link bracket while driving
for travel.
If this instruction is ignored,
there is a risk of an accident
such as rollover due to unin-
tended movement.
