Badger Meter M Series User Manual

Page 26
4-11
Model M-2000 Mag Meter
Setting Up the M-2000 with Quick Setup
The M-2000 provides you with a Quick Setup utility that allows you to set or change your Flow Units, Totalizer Units, Full Scale
Flow and Low Flow Cutoff settings. To open the Quick Setup, select Quick Setup from the Start menu.
Quick Setup
Flow Unit
[GPM]
Flow Unit lets you set the unit of measure for the flow rate and full scale flow.
To change the Flow Unit value, follow these steps from the Quick Setup menu.
1. Select Flow Unit to view the Flow Unit display.
2. Press [↑] or [↓] to position the arrow next to one of the following Flow Units:
Code Flow Unit Code Flow Unit
LPS Liter/Second GPM Gallons/Min.
LPM Liter/Minute GPH Gallons/Hour
LPH Liter/Hour MGD MegaGallon/Day
M3S Cubic Meter/Sec. IGS UKG/Sec.
M3M Cubic Meter/Min. IGM UKG/Min.
M3H Cubic Meter/Hour IGH UKG/Hour
F3S Cubic Feet/Sec. LbM Pound/Min.
F3M Cubic Feet/Min. OPM Ounce/Min
F3H Cubic Feet/Hour BPM Barrel/Min
GPS Gallons/Sec. -- --
3. Press [E] to save the Flow Units setting.
Totalizer Unit
[USG]
This parameter establishes the units of measure for the totalizers.
To change the Totalizer Unit value, follow these steps from the Totalizer Unit display.
1. Press [↑] or [↓] to position the arrow next to one of the following Totalizer Units:
Code Totalizer Unit Code Totalizer Unit
L Liters UKG Imperial Gallons
HL HectoLiters Lb Pounds
M^3 Cubic Meters Oz Fluid Ounces
CFt Cubic Feet Aft Acre Feet
USG U.S. Gallons BBL Barrel
MG MegaGallons
2. Press [E] to save the Totalizer Units setting.
