Installation & Operation Manual
Appendix: Detector Specications
Meter with M-2000 amplier Meter with junction box for remote M-2000 amplier
Size A B C D
Est. Weight
with M-2000
Flow Range
LPM
GPM
inch
mm
inch
mm
inch
mm
inch
mm
inch
mm
lbs
kg
min
max
min max
1/4 6 6.7 170 14.0 356 3.5 89 11.4 288 10 4.5 0.063 20 0.02 5
5/16 8 6.7 170 14.0 356 3.5 89 11.4 288 10 4.5 0.114 34 0.03 9
3/8 10 6.7 170 14.0 356 3.5 89 11.4 288 10 4.5 0.177 53 0.05 14
1/2 15 6.7 170 14.0 356 3.5 89 11.4 288 10 4.5 0.416 125 0.11 33
3/4 20 6.7 170 14.2 361 3.9 99 11.5 293 13 5.5 0.75 225 0.2 59
1 25 8.9 225 14.4 366 4.3 108 11.7 298 18 8.0 1.20 350 0.3 93
1 1/4 32 8.9 225 15.2 386 4.6 117 12.5 318 20 9.0 2.00 575 0.5 152
1 1/2 40 8.9 225 15.4 390 5.0 127 12.7 322 21 9.5 3.00 900 0.8 239
2 50 8.9 225 15.9 403 6.0 152 13.2 335 26 11.5 4.70 1400 1 373
2 1/2 65 11.0 280 17.1 434 7.0 178 14.4 366 52 23.5 8 2400
2 631
3 80 11.0 280 17.3 440 7.5 191 14.7 372 54 24.5 12 3600
3 956
4 100 11.0 280 18.4 466 9.0 229 15.7 398 56 25.5 19 5600
5 1493
5 125 15.8 400 19.6 498 10.0 254 16.9 430 58 26.0 30 8800
8 2334
6 150 15.8 400 20.6 524 11.0 279 17.9 456 60 27.0 40 12700
11 3361
8 200 15.8 400 22.5 572 13.5 343 20.4 518 86 39.0 75 22600
20 5975
10 250 19.7 500 26.8 681 16.0 406 24.1 613 178 81.0 120 35300
30 9336
12 300 19.7 500 28.9 734 19.0 483 26.2 666 207 94.0 170 50800
45 13444
14 350 19.7 500 30.8 782 21.0 533 28.2 716 258 117 230 69200
60 18299
16 400 23.6 590 33.7 856 23.5 597 31.0 788 306 139 300 90400
80 23901
18 450 23.6 590 35.0 890 25.0 635 32.4 822 400 181 380 114000
100 30250
20 500 23.6 590 38.2 969 27.5 699 35.5 901 493 224 470 140000
125 37346
22 550 23.6 590 39.6 1005 29.5 749 36.9 937 523 237 570 170000
150 45188
24 600 23.6 590 42.2 1071 32.0 813 39.5 1003 552 251 680 200000
180 53778
28 700 23.6 590 46.2 1173
36.5 927 44.0 1118 648 294 920 275000
240 73100
30 750 31.5 800 48.3 1228 39.0 984 45.7 1161 702 319 1060 315000
280 84000
32 800 31.5 800 52.2 1325 41.4 1015 49.5 1257 768 349 1200 361000
320 95600
36 900 31.5 800 55.3 1405 46.0 1168 54.1 1374 848 385 1500 457000
400 121000
40 1000 31.5 800 60.0 1525 50.2 1230 57.4 1457 922 419 1900 565000
500 149300
42 1050 36.0 914 66.0 1675 53.0 1346 63.4 1610 1198 499 2100 620000
550 164600
48 1200 39.4 1000 69.9 1775 59.4 1455 67.2 1707 1208 549 2700 814000
720 215100
54 1400 39.4 1000 78.5 1995 68.4 1675 75.9 1927 1362 619 3700 1100000
980 292700
Flow Range: 0.1 - 39.4 fps (0.03-12 m/s)
Sizes: 1/4 inch to 54 inches (6 mm to 1400 mm)
Min. Conductivity: ≥ 5 micromhos/cm
Accuracy:
± 0.25 percent of rate for velocities greater than
1.64 ft/s (0.50 m/s)
± 0.004 ft/s (± 0.001 m/s) for velocities less than
1.64 ft/s (0.50 m/s)
Electrode Materials: Standard: Alloy C
Optional: 316 stainless steel, gold/platinum plated,
tantalum, platinum/rhodium
Liner Material: PFA up to 3/8 inch, PTFE 1/2 inch to
24 inches, Soft and Hard Rubber from 1 to 54 inches,
Halar
®
from 14 to 40 inches
NSF Listed: Models with hard rubber liner 4-inch
size and up; PTFE liner - All sizes.
Fluid Temperature:
With Remote Amplier:
PFA, PTFE & Halar 311°F (155°C)
Rubber 178°F, (80°C)
With Meter Mounted Amplier:
PFA, PTFE & Halar 212°F (100°C)
Rubber 178°F, (80°C)
Pressure Limits:
Maximum allowable non-shock pressure and temperature
ratings for steel pipe anges, according to American
National Standard ANSI B16.5. (Example: 150-pound
anges, rated 285 PSI at ambient temperature.) (Example:
300-pound ange rated 740 PSI at ambient temperature.)
Coil Power: Pulsed DC
Ambient Temperature: -4°F to 140°F (-20°C to 60°C)
Pipe Spool Material: 316 stainless steel
Meter Housing Material: Carbon steel welded
Flanges: Carbon steel - Standard (ANSI B16.5 Class 150 RF)
316 stainless steel - Optional
Meter Enclosure Classication: NEMA 4X (IP66)
Optional: Submersible NEMA 6P (remote amplier
required)
Junction Box Enclosure Protection:
(for remote amplier option) Powder coated die-cast
aluminum, NEMA 4 (IP65)
Cable Entries: 1/2-inch NPT Cord Grip
Optional Stainless Steel Grounding Rings:
Meter Size Thickness (of one ring)
up through 10 inches .135 inch
12 to 20 inches .187 inch
