Page 29
4-11
Installation & Operation Manual
Meter Setup
Power Line Freq
[60 Hz]
S
This parameter provides measuring immunity to industrial noise from a power supply feed.
To set Power Line Frequency, follow these steps from the Meter Setup menu:
1. Select Power Line Freq to view the Power Line Frequency display.
2. Position the arrow next to 50 Hz or 60 Hz.
3. Press [E] to save the power line frequency and return to the Meter Setup menu.
Excitation Freq
[Factory Set]
A
This parameter is set at the factory. You can change Excitation Freq to configure the DC excitation of the
coils. Supported frequencies are dependent on the configured power line frequency:
50 Hz 60 Hz
1 Hz 1 Hz
3.125 Hz 3.75 Hz
6.25 Hz 7.5 Hz
12.5 Hz 15 Hz
To change Excitation Frequency, follow these steps from the Meter Setup menu:
1. Select Excitation Freq to view the Excitation Frequency display.
2. Position the arrow next the desired frequency.
3. Press [E] to save the excitation frequency and return to the Meter Setup menu.
Pipe Diameter
[Factory Set]
A
This parameter is set at the factory. In the event the amplifier is replaced, verify that the pipe diameter
matches the installed pipe size.
To change Pipe Diameter, follow these steps from the Meter Setup menu:
1. Select Pipe Diameter to open the Pipe Diameter display.
2. Position the arrow next to one of the following pipe diameters.
6mm [1/4"] 65mm [2 1/2"] 400mm [16"] 1000mm [40"]
8mm [1/4"] 80mm [3"] 450mm [18"] 1050mm [42"]
10mm [1/4"] 100mm [4"] 500mm [20"] 1200mm [48"]
15mm [1/4"] 125mm [5"] 550mm [22"] 1400mm [54"]
20mm [1/4"] 150mm [6"] 600mm [24"] 1600mm [64"]
25mm [1 "] 200mm [8"] 700mm [28"] 1800mm [72"]
32mm [1 1/4"] 250mm [10"] 750mm [30"] 2000mm [80"]
40mm [1 1/2"] 300mm [14"] 800mm [32"] Other
50mm [2"] 350mm [14"] 900mm [36"]
3. Press [E] to save the pipe diameter and return to the Meter Setup menu.
