Page 30
4-11
Model M-2000 Mag Meter
Meter Setup
Detector Factor
[Factory Set]
A
This parameter is set at the factory. This factor compensates for accuracy error as a result of the installed
detector. If accuracy adjustment of the meter is required, please refer to the scale factor.
In the event the amplifier is replaced, this parameter must be reprogrammed with the original detector
factor.
Detector Offset
[Factory Set]
A
This parameter is set at the factory. This parameter compensates for accuracy error as a result of the
installed detector. If accuracy adjustment of the meter is required, please refer to the scale factor.
Measurements
Flow Units
[GPM]
U
Flow Units lets you set the unit of measure for the flow rate and full scale flow. Changing the flow units
parameter readjusts the full scale flow parameter. For example, changing from GPM to GPS would
change the full scale flow from 60 GPM to 1 GPS.
To change the Flow Unit, follow these steps from the Measurements menu:
1. Select Flow Units to view the Flow Units display.
2. Position the arrow next to one of the following flow unit options:
Code Flow Unit Code Flow Unit
LPS Liter/Second GPM Gallons/Min.
LPM Liter/Minute GPH Gallons/Hour
LPH Liter/Hour MGD MegaGallon/Day
M3S Cubic Meter/Sec. IGS UKG/Sec.
M3M Cubic Meter/Min. IGM UKG/Min.
M3H Cubic Meter/Hour IGH UKG/Hour
F3S Cubic Feet/Sec. LbM Pound/Min.
F3M Cubic Feet/Min. OPM Ounce/Min
F3H Cubic Feet/Hour. BPM Barrel/Min
GPS Gallons/Sec.
3. Press [E] to save the flow units and return to the Measurements menu.
