TECHNICAL SPECIFICATIONS
General
Display Type High intensity transflective numeric and alphanumeric LCD, UV-resistant.
White LED backlight. Intensity adjustable from 0…100% in steps of 20%.
Good readings in full sunlight and darkness.
Digits Seven 14 mm (0.56") and ten 8 mm (0.3"). Various symbols and measuring units.
Refresh rate User definable: 8 times/sec.
Enclosure Die-cast aluminum front panel, GRP back enclosure.
Polycarbonate window, silicone gasket; UV stabilized and flame retardant material.
Keypad Sixteen industrial micro-switch keys; UV-resistant silicone keypad; replaceable
front.
Painting UV-resistant 2-component industrial painting.
Dimension 144 × 72 × 110 mm (5.67" × 2.83" × 4.33"), W x H x D.
Classification IP65 / NEMA4X at the front side.
Panel cutout 138 × 68 mm (5.43" × 2.68") W x H.
Weight 650 gram / 1.7 lb
Panel thickness Max. 6 mm (0.25").
Environment Operation –20…60° C (– 4…140° F)
Storage –40…80° C (– 40…176° F)
Humidity 85% non-condensing, relative
Power Type PG 85…265V AC. Power consumption max. 15 Watt.
24V DC + 10%. Power consumption max. 15 Watt.
Sensor excitation 8.2 / 12 or 24V DC selectable. Max. 50 mA
Terminal
Connections
Type Removable plug-in terminal strip. Wire max. 2.5 mm
2
.
Data Protection Type EEPROM backup of all setting. Backup of running totals.
Data retention at least 10 years.
Passcode Configuration settings and control keys can be passcode protected.
Lock function Complete keyboard can be locked with external input (e.g. key lock or PLC).
Environment EMC Compliant ref: EN 61326 (1997), EN 61010-1 (1993). CE and FPP certified.
Flow Meter Inputs NPN, open collector, reed-switch, active pulse signals 8, 12 and 24V.
Frequency Minimum 0 Hz, maximum 7 kHz for total and flow rate.
Maximum frequency depends on signal type and internal low-pass filter.
Example: Reed switch with low-pass filter: max. frequency 120 Hz.
K-Factor 0.000010…9,999,999 with variable decimal position.
Low-pass filter Available for all pulse signals.
Low Level 0…2V DC max.
High Level 8…20V DC max.
Impedance 4.7 kOhm pull-up to 12V DC
VDC Current 2.5 mA steady state
Industrial Process Controller, Model PC200
Page 30 April 2017CTL-UM-00483-EN-07
