Badger Meter PC200 User Manual

Conguration of the Unit
The PC200 is designed for many types of applications. Use the SETUP level to configure your PC200 to your specific
requirements. For details, see “Configuration” on page21 and “Record of Configuration Settings” on page33.
The SETUP level includes several important features, such as K-factors, measurement units and selection of the control
outputs. All settings are stored in EEPROM memory and will not be lost in the event of power failure.
Display Information
The PC200 has a large transflective LCD with a bright LED backlight and displays symbols and digits for measuring units,
status information and keyword messages.
All total, accumulated total and batch counter information is stored in EEPROM memory and will not be lost in the event of
power failure.
Industrial Process Controller, Model PC200
Page 8 April 2017CTL-UM-00483-EN-07
