DP C18.UART
CUSTOMER MANUAL FRONT HUB MOTOR SYSTEM
⑵ “Battery Info.”check
Briefly press (<0.5S)
or to select “Battery Info.” and briefly press (<0.5S) to enter into infor-
mation display interface. This moment, select “Nest Page” and briefly press (<0.5S) to switch the
display interface. If detecting no data, it display “--”. See the content and corresponding explanation
shown in the table below:
Display content Explanation Display content Explanation
TEMP Current temperature Cycle Times Cycle Times
TotalVolt Battery voltage Max Uncharge Time Max Uncharge Time
Current current Last Uncharge Time Last Uncharge Time
Res Cap
remaining battery
capacity
Total Cell The number of cell
Full Cap
Battery capacity of Full
charged
Cell Voltage 1 Voltage Cell 1
RelChargeState
Relative Charge in per-
centage
Cell Voltage 2 Voltage Cell 2
AbsChargeState
Absolute Charge in
percentage
Cell Voltage n Voltage Cell n
Briefly press
for two tiems (interval time is less than 0.5S) to exit back to main interface or select
“BACK” → “BACK” → “EXIT” to exit back to the main interface.
⑶ “Error Code” history check
Briefly press (<0.5S)
or to select “Error Code” and briefly press (<0.5S) to enter into the
interface. “E-CODE” indicate the error information for last ten times. “E-CODE 1” represents the
error content for the last time. “E-CODE 10” represents the error content up to the tenth time. The
maximum ten records can be kept. Error code “00” means no error. Please see the error code table
to know about the definition of the other codes.
