DISPLAY MANUAL DP C18.UART
ERROR CODE DEFINTION
ERROR CODE DEFINITION
DP C18.UART display can show e-bike faults. When a fault is detected, the icon will be indicated. One of the
following error codes will be indicated.
Error Explanation Troubleshooting
03 Brakes enabled Check whether a brake cable is stuck.
07 High voltage protection
Bring your Pedelec to your dealer or to a
specialist to have the error fixed.
08 Fault with motor hall sensor inside
Bring your Pedelec to your dealer or to a
specialist to have the error fixed.
10
The motor temperature reaches to
the max protection value
Stop the e-bike for a rest.
12
Fault with current sensor inside
controller
Bring your Pedelec to your dealer or to a
specialist to have the error fixed.
13
Fault with temperature sensor inside
battery
Bring your Pedelec to your dealer or to a
specialist to have the error fixed.
21
Fault with wheel speed detecting
sensor
Bring your Pedelec to your dealer or to a
specialist to have the error fixed.
22 BMS communication fault
Bring your Pedelec to your dealer or to a
specialist to have the error fixed.
25 Torque sensor torque signal fault
Bring your Pedelec to your dealer or to a
specialist to have the error fixed.
26 Torque sensor speed signal fault
Bring your Pedelec to your dealer or to a
specialist to have the error fixed.
30 Communication fault
Bring your Pedelec to your dealer or to a
specialist to have the error fixed.
Note: Error Code 10 will probably appear on the
dispaly when the e-bike is climbling for a long
time. This indicates that the motor temperature has
reached the protection value, in which case the user
needs to stop the e-bike for a rest. If the user con-
tinues to run the e-bike, the motor will automati-
cally cut off the power.
