BAFANG DP C18.UART - Error Code Definition

17
DISPLAY MANUAL DP C18.UART
ERROR CODE DEFINTION
ERROR CODE DEFINITION
DP C18.UART display can show e-bike faults. When a fault is detected, the icon will be displayed. One of the
following error codes will be displayed.
Error code Error definition Solution
"07" High voltage protection Check the battery voltage
"08" Fault with motor hall sensor inside
Have your dealer check the
motor stator
"10"
The motor temperature reaches to the max
protection value
Stop riding and wait until the
LED stop flickering
"12" Fault with current sensor inside controller
Have your dealer check the
controller
"13" Fault with temperature sensor inside battery Check the battery
"21" Fault with wheel speed detecting sensor Check the motor stator
"22" BMS Communication fault Replace the battery
"30" Communication fault
1. Check the connectors
between the EB-BUS and the
controller
2. Replace the controller
