ROOFLIGHTS
MPK ROOFLIGHT
The MPK roof light is situated in the
bathroom of your motorhome over the shower
compartment.
It is tted with a y screen for your comfort.
The y screen is hinged allowing you access
to the handles that enable you to raise the
rooight’s dome for ventilation
To raise the dome pinch the black parts of the
handle against the other half on both sides and
push upwards. Both sides can be raised or just
one depending on your preference.
MiniandMidiHekiRooights
Opening and closing the Dome
• Press the push button (1) and simultaneously
open the dome with the bar (2).
• POSITION “A”
• Push the bar (2) to the marked rest position
(•).
• Fix the bar in this position by pushing the
left and right sliding catches (3) downwards.
• POSITION “B”
• Push the bar (2) to the marked rest position
(•) and lead over the left and right locking
mechanisms by applying slight pressure.
• POSITION “C”
• Push the bar (2) to the marked rest position
(•).
• Applying slight pressure lead the bar (2)
over the left and right catch hooks (4) so
that the dome is locked and the bar (2) lies
on the push button (1).
• POSITION “D”
• Push the bar (2) to the marked rest position
(•).
OPERATING THE BLIND
• Push the blind (5) in the direction of the
arrow (A) and the yscreen (6) in the
direction of the arrow (B).
Safety instructions:
• Do not stand on the acrylic glass.
• Close HEKI completely before moving the
vehicle.
• Close HEKI when leaving the vehicle.
• Please consult your dealer when any defects
or problems occur.
• Remove snow/ice or other dirt from the roof
before opening HEKI.
• Do not open in strong winds or heavy rain.
Care instructions:
• Please clean the acrylic panes with the Seitz
Acrylic Cleaner.
• Stains and light scratches on the acrylic
pane can be removed using the Seitz
Acrylic Polish and Seitz special polishing
cloth.
• Only use water and mild soap suds to clean
the blinds.
• Failure to comply with these instructions
makes the guarantee null and void.
