Bajaj Pulsar 135 LS User Manual

How to Ride your Bike
14
• Drive smoothly and steadily at speed between 40
and 50 km/h .
• Drive at constant speed; avoid sudden accelerations
& harsh braking as far as possible. Plan your trips
properly with minimum start-stops.
• Change the gear judiciously according to the speed
requirements. Drive as far possible in highest gear.
• Travel as light as possible; do not overload the
vehicle above the specified payload.
• Stop the engine quickly at the end of the journey.
Avoid excessive idling. For intermediate stoppages,
cut-off the engine if you want to stop for more than
two minutes.
Fuel Saving Tips
Fuel Check fuel lines and connections for
leakage.
Spark plug Inspect and clean spark plug. Adjust
electrode gap.
Air filter Clean air filter element periodically.
Engine oil Check level. Use “Bajaj DTS-i
10000” high performance engine oil
for top up or refill.
Brakes Ensure that the brakes are not
dragging / binding.
Clutch Ensure correct clutch lever play.
Tyre pressure Always maintain the recommended
tyre pressure.
Carburettor Adjust idling speed.
Vehicle Maintenance (Ensure Following)
• Ensure Following Vehicle Maintenance.

Bajaj Pulsar 135 LS Specifications

General

Engine Type	4-Stroke, DTS-i, Air Cooled, Single Cylinder
Displacement	134.66 cc
Max Power	13.5 PS @ 9000 rpm
Max Torque	11.4 Nm @ 7500 rpm
Transmission	5-speed
Fuel System	Carburetor
Front Brake	240 mm Disc
Rear Brake	130 mm Drum
Fuel Tank Capacity	8 liters
Kerb Weight	122 kg
Gearbox	5-speed
Bore x Stroke	54 mm x 58.8 mm
Compression Ratio	9.8:1
Overall Length	1995 mm
Overall Width	765 mm
Overall Height	1045 mm
Wheelbase	1325 mm
Ground Clearance	165 mm
Front Suspension	Telescopic
Rear Suspension	5-way adjustable, Nitrox shock absorber
Clutch	Wet, Multi Plate
Front Tyre	2.75 x 17
Rear Tyre	100/90 x 17
Starting	Kick and Self Start
