Bajaj Pulsar 135 LS User Manual

Drive Chain Slackness
• Chain top edge to be kept between the two marks
during chain slackness adjustment.
• Care should be taken, that the chain should never
run dry.
• Lubricate chain from outside with SAE 90 oil at
every 500 kms.
• Chain slackness will have to be adjusted whenever
required.
General Maintenance Information
Wheel Puncture :
Use the recommended levers while removing the Tyre /
Tube for puncture work. This will avoid any damages to
the edges / scratches on paint of the wheel.
Tyre Pressure :
Keep appropriate tyre pressure as mentioned below to
increase life of the tyre & for better fuel consumption.
2
Front 1.75 Kg/Cm (25.0 psi)
2
Rear (Solo) 2.00 Kg/Cm (28.5 psi)
2
Rear (with Pillion) 2.25 Kg/Cm (32.0 psi)
17

Bajaj Pulsar 135 LS Specifications

General

Engine Type	4-Stroke, DTS-i, Air Cooled, Single Cylinder
Displacement	134.66 cc
Max Power	13.5 PS @ 9000 rpm
Max Torque	11.4 Nm @ 7500 rpm
Transmission	5-speed
Fuel System	Carburetor
Front Brake	240 mm Disc
Rear Brake	130 mm Drum
Fuel Tank Capacity	8 liters
Kerb Weight	122 kg
Gearbox	5-speed
Bore x Stroke	54 mm x 58.8 mm
Compression Ratio	9.8:1
Overall Length	1995 mm
Overall Width	765 mm
Overall Height	1045 mm
Wheelbase	1325 mm
Ground Clearance	165 mm
Front Suspension	Telescopic
Rear Suspension	5-way adjustable, Nitrox shock absorber
Clutch	Wet, Multi Plate
Front Tyre	2.75 x 17
Rear Tyre	100/90 x 17
Starting	Kick and Self Start
