Bajaj Pulsar 135 LS User Manual

General Maintenance Information
Battery : 12V - 5 Ah, MF
• Battery is located inside ‘Side Cover’ LH.
• Always ensure that battery electrolyte level is in
between max & min level marks.
• Check & top up battery by distilled water if
electrolyte level is below min level mark.
• Battery life would get adversely affected if top up
with ‘Tap Water’.
• Environment care must be taken to dispose off the
used battery. It is always recommended to hand over
the same to the Authorised battery / Bajaj dealer for
proper disposal of the same.
• When battery is found discharged, it is advised to get
it charged immediately.
CAUTION : Do not drive/run vehicle in battery
disconnected condition. It may lead to damage of
electrical /electronic components.
• Warranty on battery is 18 months from the date of
purchase of vehicle.
Spark Plug
• Remove spark plugs by using plug spanner.
• Clean the spark plugs.
• Adjust the gaps if incorrect by bending outer
electrode carefully.
Spark Plug Gap : 0.6~0.7 mm.
Spark Plug Make : BOSCH (2 Nos.) Or
CHAMPION (2 Nos.)
18

Bajaj Pulsar 135 LS Specifications

General

Engine Type	4-Stroke, DTS-i, Air Cooled, Single Cylinder
Displacement	134.66 cc
Max Power	13.5 PS @ 9000 rpm
Max Torque	11.4 Nm @ 7500 rpm
Transmission	5-speed
Fuel System	Carburetor
Front Brake	240 mm Disc
Rear Brake	130 mm Drum
Fuel Tank Capacity	8 liters
Kerb Weight	122 kg
Gearbox	5-speed
Bore x Stroke	54 mm x 58.8 mm
Compression Ratio	9.8:1
Overall Length	1995 mm
Overall Width	765 mm
Overall Height	1045 mm
Wheelbase	1325 mm
Ground Clearance	165 mm
Front Suspension	Telescopic
Rear Suspension	5-way adjustable, Nitrox shock absorber
Clutch	Wet, Multi Plate
Front Tyre	2.75 x 17
Rear Tyre	100/90 x 17
Starting	Kick and Self Start
