Bajaj Pulsar 135 LS User Manual

6
Left Handle Bar Switches
A. Dipper Switch : When headlight is ON, High or Low
beam can be selected with the dipper switch. Hi
beam indicator light located on Speedo console will
light up when high beam is selected.
: High Beam : Low beam
B. Turn Signal Switch : When the turn signal switch is
turned to Left ( ) or Right ( ), the corresponding
turn signals flash on and off. To stop flashing, push
the switch in and release.
C. Horn Button : ( ) Press horn button for sounding
horn.
D. Pass Switch : Press the switch to flash the head
light. It is used to give signal to vehicles coming
from opposite side while overtaking.
D
A
B
C
Location of Parts

Bajaj Pulsar 135 LS Specifications

General

Engine Type	4-Stroke, DTS-i, Air Cooled, Single Cylinder
Displacement	134.66 cc
Max Power	13.5 PS @ 9000 rpm
Max Torque	11.4 Nm @ 7500 rpm
Transmission	5-speed
Fuel System	Carburetor
Front Brake	240 mm Disc
Rear Brake	130 mm Drum
Fuel Tank Capacity	8 liters
Kerb Weight	122 kg
Gearbox	5-speed
Bore x Stroke	54 mm x 58.8 mm
Compression Ratio	9.8:1
Overall Length	1995 mm
Overall Width	765 mm
Overall Height	1045 mm
Wheelbase	1325 mm
Ground Clearance	165 mm
Front Suspension	Telescopic
Rear Suspension	5-way adjustable, Nitrox shock absorber
Clutch	Wet, Multi Plate
Front Tyre	2.75 x 17
Rear Tyre	100/90 x 17
Starting	Kick and Self Start
