Baldor VS1MD - Specifications for Power Terminal Block Wiring

Power Wiring 4-5
4.4 Specifications for Power Terminal Block Wiring
VS1MD20P5, VS1MD21, VS1MD40P5, VS1MD41, VS1MD22, VS1MD42
VS1MD23, VS1MD43, VS1MD25, VS1MD45
VS1MD27, VS1MD210, VS1MD47, VS1MD410
* Strip the sheaths of the wire insulation 7mm when a ring terminal is not used for
power connection.

RSTB1B2
UVW
RSTB1B2UVW
B1 B2 U V W
RST
Model
Number
R,S,T
wire size
U, V, W
wire size
Ground Wire Screw
size
Terminal
torque
mm
2
AWG
mm
2
AWG
mm
2
AWG Terminal
Screw
Size
Screw
Torque
(Kgf.cm/lb-in)
VS1MD20P5
2 14 2 14 3.5 12 M3.5 10/8.7
VS1MD21
2 14 2 14 3.5 12 M3.5 10/8.7
VS1MD22
2 14 2 14 3.5 12 M3.5 10/8.7
VS1MD23
2 14 2 14 3.5 12 M4 15/13
VS1MD25
3.5 12 3.5 12 3.5 12 M4 15/13
VS1MD27
5.5 10 5.5 10 5.5 10 M5 32/28
VS1MD10
8 8 8 8 5.5 10 M5 32/28
VS1MD40P5
2 14 2 14 2 14 M3.5 10/8.7
VS1MD41
2 14 2 14 2 14 M3.5 10/8.7
VS1MD42
2 14 2 14 2 14 M4 15/13
VS1MD43
2 14 2 14 2 14 M4 15/13
VS1MD45
2 14 2 14 2 14 M4 15/13
VS1MD47
3.5 12 2 14 3.5 12 M5 32/28
VS1MD410
3.5 12 3.5 12 3.5 12 M5 32/28
