Page #45 background imageLoading...
Page #45 background image
www.balluff.com 19english
Further data can be found at www.balluff.com
on the product page.
9.1 Ambient conditions
Ambient temperature −10...+70°C
Storage temperature −25...+85°C
Protection per IEC60529 (when
threaded together)
IP40
9.2 Electrical data
Supply voltage U
e
15/24/30VDC
1)
Current draw (no-load) I
0
≤25mA
Switching current I
e
≤50mA
Voltage drop (at 100mA) ≤2V
Capacitive load 220nF
Switching frequency f 100Hz
Possible power amplifier setting
2)
PNP N.O., PNP N.C,
NPN N.O., NPN N.C.,
push-pull N.O.,
push-pull N.C.
Short-circuit protection yes
Reverse polarity protection yes
Protection against miswiring yes
Overvoltage protection yes
1)
Values: minimal/nominal/maximal
2)
Via teach line (open towards U
B
) or menu
9.3 Electrical connection
Connection
BAE …-BP00,3-GS04 M12x1-Male
BAE …-BP02 open cable end,
4conductors
9.4 Approvals and markings
The CE Mark verifies that our products
meet the requirements of the current EU
Directive.
Additional information on directives, approvals and
standards can be found at www.balluff.com on
the product page.
9
Technical Data
BAE SA-CS-026-YP-BP02 / BAE SA-CS-026-YP-BP00,3-GS04
Comfort Sensor Amplifier
