Balluff Micropulse BTL5-A series User Manual

WWW.BALLUFF.COM • 1-800-543-8390
13
™
BTL5-A/C/E/G__-M____-B/Z-S32/KA__
Micropulse Linear Position Transducer
Analog Output-Rod Style
7 Magnet and Control Arm Diagram References
0.5
74
12
~ 27~ 27
~ 53
11
Ø 6.5
25
60 ±0.5
Ø 10.2
45
SW 46
1 2
Nominal length
= measuring range
Damping zone (unusable area)
Mounting
surface
Electrical connection
Magnet
Thread size: B: M18×1.5 (includes nut)
Z: 3/4"-16UNF
B: 30 mm
Z: 2"
Blind hole
M4 × 4/6 deep
Magnet
BTL5...B/Z-KA05
BTL5...B/Z-S 32
Calibration
device
Fig. 3-2: Transducer BTL5...B/Z, Dimensions
straight BKS-S 32M-00
No. 99-5672-19-08
(Binder part no.)
right-angle BKS-S 33M-00
No. 99-5672-78-08
(Binder part no.)
Cable entry (PG 9 fitting)
Fig. 4-3: Connector (optional)
1 2
1
2
Fig. 3-4: Magnet (optional)
BTL-P-1013-4R
BTL-P-1013-4S
BTL-P-1012-4R
Fig. 6-1: Calibration device
(shown on transducer)
= Button 2
gray
= Button 1
blue
Z_Analog_122003.pmd 12/11/2003, 3:47 PM13
