Rapid Replacement Module
Micropulse Linear Position Transducers
Installation Guide for
Rapid Replacement Module
Rapid Replacement Module
Micropulse Linear Position Transducers
WWW.BALLUFF.COM
•
1-800-543-8390
Rapid Replacement Module
Micropulse Linear Position Transducers
Overview
The Rapid Replacement Module (RRM) allows the electronics module
and waveguide assembly to be quickly and easily replaced without
removing the pressure tube.
Ordering Information
The RRM can be ordered as a complete unit, or as a replacement
module only. The replacement module can only be used with Balluff
BTL5-series linear transducers.
The ordering codes are shown below:
Ordering Example 1
Complete transducer unit with RRM + pressure tube
BTL5-xxx-Mxxxx-ZM-xxx
Add "M" after "Z"
BTL5-xxx-Mxxxx-ZM-xxx/RU
Add "M" after "Z"
Add "/RU" at end of ordering code
Included with "RU" Replacement Unit:
- Electronics head/sensing element unit
- Replacement housing gasket
- (2) M4x60 housing retaining screws
Ordering Example 2
Rapid Replacement Module Only
Untitled-1 6/17/2005, 2:30 PM2
