MODELS 2550/2550T
2550 - REMOTE CONTROLS
Make sure to order components according to tting type, ttings may vary on all components.NOTICE
Hydraulic components, ttings, hoses will vary depending on optional equipment.
Order by physical description.
# Part Number Description
1 See pp 78-79 Hydraulic Tank
2
900-3951-31 In Tank Filter (Start 11/12)
900-3951-32 Filter Element Only (Start 11/12)
900-3938-23 In Tank Filter (Pre 11/12)
900-3938-96 Filter Element Only (Pre 11/12)
3 900-3944-78 Tank Strainer
4 900-3943-65 1/4” Ball Valve
5
900-3982-94 Cutter Wheel Pump (Start 1/17)
900-3955-97 Cutter Wheel Pump (Pre 1/17)
6
900-3955-82 High Pressure Filter
900-3944-57 Filter Element Only
7
900-3959-06
Cutter Wheel Motor
(Start 4/14)
900-3951-17 Cutter Wheel Motor (Pre 4/14)
900-3955-99
Cutter Wheel Motor Manifold
Relief
900-3956-04 Relief Only
8 See Check Sheet Auxiliary Pump
9
900-3946-01 Remote Manifold Assembly
900-3928-25 Brake Hand Pump (HP1)
900-3945-71 Brake Release Needle (NV2)
900-3945-73
Brake Release Check (CV1,
CV2)
900-3945-74
Brake Release Shuttle (LS1,
LS2)
900-3945-75
Dual Pressure Override Check
(DC1 - DC3)
900-3929-09
Drive/Swing Counter Balance
(CBV1, CBV2)
900-3945-79 Flow Divider 4WD Only (FD1)
900-3945-77 Cavity Plug 2WD Only (FD1)
900-3934-53 Solenoid & Cartridge
900-3954-71
Bi-Directional Relief: Swing,
Blade, Steer (CR2 - CR4)
900-3952-66
Cutter Wheel Down Relief (RV1) /
Main Relief (RV2)
900-3957-22
Drive/Swing Flow Control (FR1,
FR2)
900-3956-99
.030” Brake Release Orice
(ORF1)
# Part Number Description
10 900-3952-11 Oil Cooler
11 900-3947-20 Braking Motor
12 900-3947-21 Non-Braking Motor
13 900-3937-68 Steering Cylinder
14 900-3940-29 Cutter Wheel Lift Cylinder
15 900-3958-80 Swing Cylinder
16 900-3002-51 Dual Counter Balance Valve
17 900-3946-87 Blade Cylinder
HYDRAULIC DIAGRAM
