Bandit
91
Copyright 4/21
MODELS 2550/2550T
Make sure to order components according to tting type, ttings may vary on all components.NOTICE
Hydraulic components, ttings, hoses will vary depending on optional equipment.
Order by physical description.
2550T - MANUAL / SWING OUT CONTROLS
# Part Number Description
1 See pp 78-79 Hydraulic Tank
2
900-3951-31 In Tank Filter (Start 11/12)
900-3951-32 Filter Element Only (Start 11/12)
900-3938-23 In Tank Filter (Pre 11/12)
900-3938-96 Filter Element Only (Pre 11/12)
3 900-3944-78 Tank Strainer
4
900-3982-94 Cutter Wheel Pump (Start 1/17)
900-3955-97 Cutter Wheel Pump (Pre 1/17)
5
900-3955-82 High Pressure Filter
900-3944-57 Filter Element Only
6
900-3959-06
Cutter Wheel Motor
(Start 4/14)
900-3951-17 Cutter Wheel Motor (Pre 4/14)
900-3955-99
Cutter Wheel Motor Manifold
Relief
900-3956-04 Relief Only
7 See Check Sheet Auxiliary Pump
8 900-3976-23 5 Function Valve Bank
# Part Number Description
9 900-3956-11 Oil Cooler
10 900-3924-30 Swing Speed Adjust
11
900-3930-99 Super Sweep Valve
900-3978-67 Super Sweep Subplate
12 900-3002-51 Dual Counter Balance
13 900-3958-80 Swing Cylinder
14 900-3940-29 Cutter Wheel Lift Cylinder
15
900-3935-35 2-Speed Block
900-3935-82 Solenoid Only
16 900-3959-99 Left Track Motor
17 900-3959-99 Right Track Motor
18 900-3946-87 Grading Blade Cylinder
HYDRAULIC DIAGRAM
