Bandit 490 - Page 29

Bandit
Copyright 11/10 PAGE 29
MODEL 490
MAINTENANCE SECTION
LUBRICATION CHART
NOTICE Use as a reference only, locations may vary depending on options or component manufacturer.
Lubrication point instructions are described on the machine, in the Lubrication & Coolant Section
and Maintenance Section of this manual, or component manufacturer’s manual.
