Asset Monitoring Gateway With SNAP ID Instruction Manual


4
•
•
•
•
•
•
•
The items included with the Asset Monitoring Gateway with SNAP ID are:
4" Banner Touch Screen HMI with Ethernet connection
M12 power and serial communications input connector
PSW-24-1 power supply
Polycarbonate enclosure
STPM12406cordset(notincludedwithcellularmodels)
Mounting bracket packet
Stylus,modelSTYLUS-1(p/n10602)
Dimensions
All measurements are listed in millimeters, unless noted otherwise.
AMG dimensions
177 mm
216 mm
105 mm
