159R5905752 /16 DP2K C
A.6 Dimensions of the DP2K-xxC
Dimensions
485
694
699
1020
49
485
499
699
779,5
456
min. 53
max. 173
558
201
333,5
115
Image A–1 Dimensions are given in mm.
