R5905752 /16 DP2K C78
Source: 3D-HFR
General settings Advanced settings
Port Port type Mode Scan type Color
space
Pixel mapping Calibration
Dual
(separate left
/ right eye)
Progressive SF-
2nd field dominant
YCbCr 3G - Level A -
Interleaved
Single
Dual
(separate left
/ right eye)
6.7 Integrated Media Block/Server (optional)
Not available for purchase at Barco for use in Taiwanese market.
Depending on the projector configuration the projector card cage is either equipped with an ICP(-D)
or ICMP-X. In case an ICP(-D) is installed then an IMB, IMS, or HDSDI input module can be
optionally inserted into the slot below the ICP(-D). This is not the case if the ICMP-X is installed. For
more information about the ICMP-X see chapter called ICMP-X.
Integrated Media Block (IMB)
Image 6–6 Example of IMB powered by Dolby.
Integrated Media Server (IMS)
Image 6–7 Example of IMS powered by Dolby.
Configuration and operation instructions for IMB and IMS are not included in this document. See
manufacturers website of the installed IMB/IMS for technical documentation and support.
Input & communication
