R5906113 /08 UDX128
A.10 Dimensions of a UDX
Overview
1
624
437
223
36
385
796 2020
836
624
312
408
20 20
664
Image A-1: Dimensions, in mm
1 Geometrical centre
A.11 Dimensions of the rigging frame
Overview
50
1018,97
463,3 978,38
385
843,94
773,72
803,38
Image A-2: Dimensions, in mm
