Barco UDX

R5906113 /08 UDX140
Video timing
(active pixels x active
lines)
Vertical refresh rate
(Hz)
Available layout modes,
other than standard
layout (1 x 1 layout)
10
Support for 3D?
640 x 480 60
800 x 600 60
960 x 1080 120 4 Quadrant mode (2 x 2
layout)
Active 3D
960 x 1200 120 4 Quadrant mode (2 x 2
layout)
Active 3D
960 x 2160 120 4 Column mode (4 x 1
layout)
Active 3D
960 x 2400 120 4 Column mode (4 x 1
layout)
Active 3D
1024x 768 60
1024 x 2160 60 4 Column mode (4 x 1
layout)
1024 x 2160 120 4 Column mode (4 x 1
layout)
Active 3D
1280 x720 50
1280 x 720 60
1280 x 800 60
1280 x 960 60
1280 x1024 60
1280 x 1080 60 4 Quadrant mode (2 x 2
layout)
1280 x 1080 120 4 Quadrant mode (2 x 2
layout)
Active 3D
1280 x 1600 60 4 Quadrant mode (2 x 2
layout)
1280 x 1600 120 4 Quadrant mode (2 x 2
layout)
Active 3D
1400 x 1050 60
1600 x 1200 60
1600 x 1200 120 Active 3D
1920 x 1080 50
1920 x 1080 60
1920 x 1080 120 4 Quadrant mode (2 x 2
layout)
Active 3D
1920 x 1200 50
1920 x 1200 60
1920 x 1200 120 4 Quadrant mode (2 x 2
layout)
Active 3D
Overview video timings for video interfaces
10: Other layout modes are only available on Input boards that have multiple DP inputs.
