Bard MC5000 Series User Manual

TABLE 1
MC5000 Series Set Points/Defaults/User Settings Record
Set Point (SP) or Item Name Current Range Default User Settings
Cooling Set Point 4° above Heating SP to 90°F 77
Heating Set Point 32°F to 4° below Cooling SP 60
Comfort Mode Cooling Set Point 4° above Comfort Heating SP to 90°F 72
Comfort Mode Heating Set Point 32°F to 4° below Comfort Cooling SP 68
Dehumidification Level 10-100% RH +10% above Humidification Level 80%
Humidification Level 0-90% RH +10% under Dehumidification Level 45%
Cooling Interstage Differential .5 – 5 1
Cooling Off Differential .5 – 5 2
Heating Interstage Differential .5 – 5 1
Heating Off Differential .5 – 5 2
Dehumidification Interstage Differential 0 – 5 5
Dehumidification Off Differential 1 – 15 10
Humidification Interstage Differential 0 – 5 5
Humidification Off Differential 1 – 15 10
High Humidity Alarm Set Point 65 – 95 85
Low Humidity Alarm 0 – 80 25
Low Temperature Alarm Level 65 – 28 40
High Temperature Alarm Level 1 70 – 120 80
High Temperature Alarm Level 2 70 – 120 90
Heat Pump Lockout Range None, 5 – 50 None
Equipment Setup Items
Number of HVAC Units 1 – 6 1
Number of Compressor Stages 1 or 2 1
Heat Pump Enabled Yes or No No
O/B Configuration Energize in Heating or Energize in Cooling Heating
Number of Electric Heat Stages 1 or 2 1
Max Units in Generator Mode 1 – 6 6
Number of Dehumidification Units 0 – 6 0
Dehumidification Type Mechanical, Synchronized or None None
Dehumidification Count 0 – 6 0
Humidification Yes or No No
Economizer Present Yes or No No/Hidden
Dust Sensor Type Dry Contact, Analog or None
Dry Contact/
Hidden
Continued on page 22
Manual 2100-746
Page 22 of 55
