Bard MEGA-TEC W150A - Page 143

Manual 2110-1451D
Page 25 of 28
Dwg. No. Part Number Description
1 135-388 Recessed Actuator Box 2
2 1012-201 1/4"-20 Steel Keps Nut 4
3 8602-040 BKP-24 Butterfly Pivot 8
4 137-904 Intake Partition 2
5 1921-067-0900 9" Damper Blade Seal 4
6 8406-150 Blade Switch 2
7 1921-067-3012 30-3/4" Damper Blade Seal 4
8 141-486 Damper Blade Support 2
9 8602-042 1/4" X 6" Rod 2
10 139-396 Damper Blade 2
11 8602-008 Ball Joint 2
12 1012-174 1/4"-20 x 3-1/4" Bolt 4
13 8602-078 Crank Arm 2
14
14
14
910-2082
910-2083
8602-098
Direct Coupled Actuator w/Crank Arm (Right Side)
Direct Coupled Actuator w/Crank Arm (Left Side)
Actuator Only
1
1
1
15 113-727 Actuator Mounting Bracket 2
16 113-730 Hinge Bracket 2
17 1012-343 1/4'-28 x 1/2" Bolt 6
18 1012-348 1/2" x 3/4" Nylon Flat Washer 4
W090A****E W120A****E W150A****E
INTAKE DAMPER ASSEMBLY
