Bard MEGA-TEC W150A - LC6000 CONTROLLER INSTALLATION

Manual 2100-705B
Page 18 of 43
LC6000 CONTROLLER INSTALLATION
FIGURE 14
Typical LC6000-200 Component Location
Transformer
RJ11 Cable
to Display
Four Fused
Power Supply
Terminals
Terminal Block
Emergency Off
Alarm Jumper
Emergency Vent
Alarm Jumper
Generator Run
Alarm Jumper
Control Board
Ethernet Cable
Connection
USB Male A
to Micro Male
B Cable
