Manual 2100-705B
Page 11 of 43
FIGURE 6
Electric Heat Clearance
FIGURE 7
Wall Mounting Instructions
WOOD FRAME WALL INSTALLATION
SUPPLY AIR
OPENING
RETURN AIR
OPENING
WOOD OR STEEL SIDING
DUCT
RETURN AIR
OPENING
SUPPLY AIR
WALL STRUCTURE
SUPPLY AIR
CONCRETE BLOCK WALL INSTALLATION
RETURN AIR
OPENING
OPENING
MIS-3947
BEFORE INSTALLATION
SIDE VIEW
FACTORY SUPPLIED
RAIN FLASHING.
MOUNT ON UNIT
