61-101-00802.EF2 (REV. G) CH. 2
January 7, 2015 Page 24 of 44
(23) Push and hold the PRESS TO READ CAP (pF) pushbutton while
adjusting CAP SIM (pF) control knobs. Verify that the T/S displays
64.1 pF.
(24) Release pushbutton.
(25) Set the MAIN/TOT-AUX/NAC switch to AUX/NAC.
(26) Rotate TEST FUNCTION switch to IND AMP.
(27) Verify the indicator reads 0 lbs.
(28) If reading is not 0 lbs., adjust the indicator using the EMP 2/E 2
switch located at rear of indicator.
(29) If the indicator still does not read 0, replace the indicator.
(30) Repeat steps (1) thru (29) until an accurate gage adjustment is
obtained.
(31) Set the MAIN/TOT – AUX/NAC switch to MAIN/TOT.
(32) Rotate the TEST FUNCTION switch to CAP SIM CAL (NORM SYS).
(33) Set the 200 (pF)/1000 (pF) switch to 1000 (pF).
(34) Set the CAP SIM (pF) 100’s thumbwheel to 1 and the 10’s
thumbwheel to 7 (UA and UB). Set 100’s and 10’s thumbwheels to 1
and 8 (UC and UE).
(35) Press and hold the PRESS TO READ CAP (pF) pushbutton while
adjusting the CAP SIM (pF) control knob to obtain a test set reading
of 178.9 pF (UA and UB) or 185.0 pF (UC and UE).
(36) Rotate the TEST FUNCTION switch to IND AMP.
(37) Verify the indicator reads 300 ±35 lbs.
(38) Rotate the TEST FUNCTION switch to CAP SIM CAL (NORM SYS).
(39) Set the CAP SIM (pF) 100’s thumbwheel to “2”. Set the 10’s
thumbwheel to “0” (UA and UB) or to “1” (UC and UE).
(40) Press and hold the PRESS TO READ CAP (pF) pushbutton while
adjusting the CAP SIM (pF) control knob to obtain a test display of
201.2 pF (UA and UB) or 210.0 pF (UC and UE).
(41) Rotate the TEST FUNCTION switch to IND AMP.
(42) Verify the indicator reads 600 ±35 lbs.
(43) Rotate the TEST FUNCTION switch to CAP SIM CAL (NORM SYS).
(44) Set the CAP SIM (pF) 100’s thumbwheels to “2”. Set the 10’s
thumbwheel to “2” (UA and UB) or to “3” (UC and UE).
(45) Press and hold the PRESS TO READ CAP (pF) pushbutton while
adjusting CAP SIM (pF) control knob to obtain a test set display of
223.6 pF (UA and UB) or 236.0 pF (UC and UE).
(46) Rotate the TEST FUNCTION switch to IND AMP.
(47) Verify the indicator reads 900 ±35 lbs.
(48) Rotate the TEST FUCTION switch to CAP SIM CAL (NORM SYS).
(49) Set the CAP SIM (pF) 100s thumbwheel to “2”. Set the 10s
thumbwheel to “4” for the UA and UB or “6” for the UC and UE serial
numbers.
