HYDRAULIC PRESSURE SETTINGS (495ML)
RELIEF VALVES
TheReliefValveportionofthecontrolvalvesinyourBarkoLoaderlimittheowofhydraulicoil,whichrelieves
the excess pressure in the hydraulic system, if for any reason pressure is built up above a predetermined, safe,
maximum.
CAUTION
The relief valve pressure setting has been arrived at by our engineers after
considerable experience with and testing of this loader. The setting will provide
maximumsafetyandefciencyofoperation.DONOTALTERTHISRELIEF
SETTING! Relief settings increased beyond this setting could be dangerous to life,
limb and property.
The following is a list of pressure settings used on your Barko Loader. Any questions should be directed to the
factory. Phone 715-395-6700.
K170 UPPER VALVE SYSTEM (see also Hydraulic Pressure Adjustments for the K170 Valve):
Pump Compensator (working pressure) ........................................ 3600 PSI (248 Bar)
Main Boom - up (butt end of main boom cylinder)......................... 4000 PSI (276 Bar).......... at the Port Relief.
Main Boom - down (rod end of main boom cylinder) ..................... 1800 PSI (124 Bar).......... at the Port Relief.
Stick Boom - up (butt end of secondary boom cylinder) ................ 4000 PSI (248 Bar).......... at the Port Relief.
Stick Boom - down (rod end of secondary boom cylinder) ............ 4000 PSI (248 Bar).......... at the Port Relief.
Live Heel Boom - up (butt end of live heel boom cylinder) ............ 4000 PSI (248 Bar).......... at the Port Relief.
Live Heel Boom - down (rod end of live heel boom cylinder) ........ 1800 PSI (124 Bar).......... at the Port Relief.
Open/Close - ports A & B............................................................... 2500 PSI (172 Bar).......... at the Feed
Reducers.
Rotate - ports A & B ....................................................................... 1500 PSI (103 Bar).......... at the Feed
Reducers.
Main Relief..................................................................................... 4000 PSI (276 Bar)
Swing System (high pressure reliefs) ............................................ 3600 PSI (248 Bar).......... both right and left.
Servo System (servo relief valve) ................................................... 450 PSI (31 Bar)
K170 STEERING/TRAVEL VALVE SYSTEM:
Travel .............................................................................................. 450 PSI (31 Bar).............at the Port Relief
Steering ..........................................................................................450 PSI (31 Bar)............at the Feed Reducer
MACHINE FUNCTION SPEEDS
Swing ...................................................... 9 RPM (7 seconds per revolution)
Main Boom ............................................. 9 seconds extend
................................................................ 11 seconds retract
Stick Boom ............................................. 7 seconds extend
................................................................ 9 seconds retract
Grapple Open/Close ............................... 4 seconds close
................................................................ 3 seconds open
Grapple Rotate ....................................... 30 RPM (2 seconds per revolution)
Bar Up & Knives ............................................................................ 1800 PSI (124 Bar)
