Service Manual
495B SE (S)
5
Last Updated - 9/28/2016
ABBREVIATIONS AND SYMBOLS
EXPLANATIONS OF OTHER OCCURRENCES IN THIS MANUAL:
- In a parts list, when there are item numbers with empty spaces (no description or part number), these parts
have been previously deleted from that parts list and are not recorded anywhere.
- In a parts list, when there are items with no part number and a dotted line (----) is in the part number space,
this means that the part number is not sold separately or is not available at this time.
- When references to "right hand" or "left hand" are used in this manual, it is done from the operator's seat in
the forward operating position.
a/c = air conditioner
AC = Articulated Carrier (Art. Car.)
adj. = adjust or adjusting
appl. = application
AR = As Required
assy = assembly
BC = Back of Cab
b/m = bill of material
brg. = bearing
CAR = Carrier
coll. = collector
cond. = conditioner
CRL = Crawler
cyl. = cylinder
dia. = diameter
dwg. = drawing
Ft. Lbs. = Foot Pounds
gal. = gallon
HRT = Hydrostatic Rough Terrain carrier
ill. or illus. = illustration
In. Lbs. = Inch Pounds
incl. = includes or including
j.s. = joystick
Lbs. = pounds
LH (lh) = left hand
mtg. = mounting
N/A = Not Applicable
no. = number
NSS = Not Sold Separately
opt. = optional
pg. = page
qt. = quart
RH (rh) = right hand
sec. = secondary
see sep. ill. = see separate illustration (means:
located elsewhere in manual)
SE = Stationary Electric
SER or SR = Stationary Electric Remote
s/n = serial number
str. = straight
swhd = saw head
TM = Truck Mount
w/ = with
