BCS36x8
ex
Series Connection example
Type 17-A1S4-*HP* and B7-A2S4-****
Subject to technical changes.
05/2020
Page 21 of 78
6. Bluetooth BCS3678
ex
hand-held scanner
6.1 Connection RS232 to PC via universal supply module
6.1.1 Components required
Functional system
BCS3678
ex
-IS
ATEX / IECEx Zone 1/21
NEC / CEC Class I, II, III Division 1
BCS3678
ex
-NI
ATEX / IECEx Zone 2/22
NEC / CEC Class I, II, III Division 2
1 x Bluetooth BCS3678
ex
hand-held scanner
Type: 17-A1S4-2HP1 Type: B7-A2S4-2HP1 or B7-A2S4-2ER1
1 x Universal supply module for hand-held scanner
ATEX / IECEx Zone 1/21
Type: 17-A1Z0-0019
ATEX / IECEx Zone 2/22
Type: B7-A2Z0-0043
NEC / CEC Class I, II, III Division 2
Type: B7-A2Z0-0043US
To be provided by the customer
1 x
1 x RS232 connection cable to the host PC
Maximum cable length supported: 15m
Number of cores and recommended cable cross section: see BARTEC User Manual.
(http://automation.bartec.de/scanner.htm )
NB:
– The default setting for the hand-held scanner is as HID device. The serial
interface still needs to be activated with the help of a programming barcode.
The universal supply module is then detected by the host PC as a series connection.
– Please use standard, shielded data lines to prevent external disturbances.
Recommendation: e.g. use CAT5, similar or higher quality cables
1 x PC with serial (COM) interface
1 x
Terminal program or software keyboard wedge for testing virtual COM communication and data
transmission on the host PC.
