Bartec BCS36 8ex Series Supplementary Description

BCS36x8
ex
Series Connection example
Type 17-A1S4-*HP* and B7-A2S4-****
Subject to technical changes.
05/2020
Page 75 of 78
15. Bluetooth BCS3608
ex
hand-held scanner with HMI
limiting cable
15.1 Connection USB limiting cable (e.g. on Ex-HMI)
15.1.1 Components required
Functional system
BCS3608
ex
-NI
ATEX / IECEx Zone 2/22
NEC / CEC Class I, II, III Division 2
1 x Wired BCS3608
ex
hand-held scanner
Type: B7-A2S4-2HP0
1 x HMI limiting cable for connection between Ex-HMI device and hand-held scanner
Type: B7-A2Z0-0041 or B7-A2Z0-0054
To be provided by the customer
1 x Ex-HMI device with USB 2.0 or USB 3.0 interface
Ex-relevant and functional parameters required for the function:
USB interface must supply 5V
DC
/500 mA output side.
If these values are not supplied by the interface, connection can be realized via universal supply
module.
The Ex-relevant data of the hand-held scanner must match the Ex-relevant data of the Ex-HMI
or any other Ex-device.
The Ex-relevant data of the BARTEC systems can be found in the corresponding Ex certificates,
user manuals and data sheets. (www.bartec.com )
