BCS36x8
ex
Series Connection example
Type 17-A1S4-*HP* and B7-A2S4-****
Page 8 of 78
Subject to technical changes.
05/2020
4. Wired BCS3608
ex
hand-held scanner
4.1 Connection RS232 to PC via universal supply module
4.1.1 Components required
Functional system
BCS3608
ex
-IS
ATEX / IECEx Zone 1/21
NEC / CEC Class I, II, III Division 1
BCS3608
ex
-NI
ATEX / IECEx Zone 2/22
NEC / CEC Class I, II, III Division 2
1 x Wired BCS3608
ex
hand-held scanner
Type: 17-A1S4-1HP0 Type: B7-A2S4-1HP0 or B7-A2S4-1ER0
1 x Universal supply module for hand-held scanners
ATEX / IECEx Zone 1/21
Type: 17-A1Z0-0018
ATEX / IECEx Zone 2/22
Type: B7-A2Z0-0042
NEC / CEC Class I, II, III Division 2
Type: B7-A2Z0-0042US
1 x Connection cable for connection between universal supply module and scanner
Type: 17-A1Z0-0015 or 17-A1Z0-0016 or
17-A1Z0-0017
Type: B7-A2Z0-0037 or B7-A2Z0-0038 or
B7-A2Z0-0039
To be provided by the customer
1 x
1 x RS232 connection cable to the host PC.
Maximum cable length supported: 15 m
Number of cores and recommended cable cross section: see BARTEC User Manual.
(http://automation.bartec.de/scanner.htm)
NB:
– The default setting for the hand-held scanner is as an HID device. The serial
interface still needs to be activated with the help of a programming barcode.
The universal supply module is then detected by the host PC as a series connection.
– Please use standard, shielded data lines to prevent external disturbances.
Recommendation: e.g. use CAT5, similar or higher quality cables
1 x PC with serial (COM) interface
1 x
Terminal program or software keyboard wedge for testing virtual COM communication and data
transmission on the host PC.
