Bartec BCS36 8ex Series Supplementary Description

BCS36x8
ex
Series Connection example
Type 17-A1S4-*HP* and B7-A2S4-****
Subject to technical changes.
05/2020
Page 35 of 78
8. Bluetooth BCS3678
ex
hand-held scanner
8.1 Connection via cradle as HID device to host PC
8.1.1 Components required
Functional system
BCS3678
ex
-IS
ATEX / IECEx Zone 1/21
NEC / CEC Class I, II, III Division 1
BCS3678
ex
-NI
ATEX / IECEx Zone 2/22
NEC / CEC Class I, II, III Division 2
1 x Bluetooth BCS3678
ex
hand-held scanner
Type: 17-A1S4-2HP1 Type: B7-A2S4-2HP1 or B7-A2S4-2ER1
1 x
Cradle for hand-held scanner (data communication and charging the battery in the hand-held
scanner)
17-A1Z0-0014 Type: G7-A0Z0-0010
1 x Power supply unit with DC connection cable
G7-A0Z0-0019 G7-A0Z0-0019
1 x AC mains lead
- US + Canada G7-A0Z0-0024
- EU + APAC G7-A0Z0-0026
- TAIWAN G7-A0Z0-0027
- US + Canada G7-A0Z0-0024
- EU + APAC G7-A0Z0-0026
- TAIWAN G7-A0Z0-0027
1 x Connection cable - USB: 1.9 m (smooth) – connection between cradle and host PC
17-A1Z0-0020 G7-A0Z0-0018
To be provided by the customer
1 x PC with USB 2.0 or USB 3.0 interface
The hand-held scanner is set as an HID device in factory defaults, and can be directly connected
to the USB of the host PC.
