TURRET
MODEL
1 2 3
TB
N° pos
4 5 6 Profile 7 8 9 10
TB 120/160 - - - 8 - -
Voltage setting
Univ. - -
Drive Set-up
Acquisition
TB 200/250 - - 12 - Fast -
TB 320 - - 16 - Medium -
TB 400 - 24 Slow
TB 100 - -
TAB
N° pos
4 5
TAB 210/265
4
(if set K3)
- -
TAB 340/440
8
(if set K5)
- -
6
(if set K3)
-
Custom
12
(if set K5)
-
24
(if set K5)
DIPSWITCH N° MOTOR TYPE
6
400V 50/60Hz
6
230V 50/60Hz
Sequence of operations N°3:
1. Drive OFF (24Vdc Off)
2. Set all the dip switches OFF
3. Set ON the dipswitches according to the turret and
the input voltage (see table below)
4. Turn ON the Drive
5. Set to ON the dipswitch n°10 and after 5" switch to
off (ACQUISITION PROCEDURE)
ON OFF
ON OFF
