Basalte B.link - 3.2 Surround receivers

B.link
Manual
6 / 32 v.1.1 © 2014 basalte
3.2 Surround receivers
B.link can control up to three surround receivers directly over IP without the need for B.link
Flex module. The network enabled surround receivers from Pioneer, Marantz and Denon are
supported, configuration is done using ETS and do not require the B.link configuration tool.
Parameter Description
Surround receiver brand Select the corresponding brand of surround receiver
1 = Pioneer
2 = Denon
3 = Marantz
Ramp time (0-100%) This parameter defines the time to set the volume from the
minimum to the maximum.
This ramp time should be set identical to the ramp time
defined in the modules controlling the music volume.
For instance, when using a Deseo to control the volume
with slider feedback, the ramp time of the Deseo must be
equal to the ramp time in the B.link.
Settings
From 3 sec to 12 sec with steps of 0.5 sec (default 6 seconds)
