Dimensions
FUNCTIONAL DESCRIPTION OF THE SYSTEM
Front view
• Control panel with large display and keyboard (see description on next page)
• Peristaltic pump for acid dosage
• Peristaltic pump for chlorine dosage
Bottom view: connections
• POWER Power cable (pre-wired)
• pH BNC connector for pH electrode
• RX BNC connector for redox electrode
• LEV1 Connector for level sensor of tank 1 (acid)
• LEV2 Connector for level sensor of tank 2 (chlorine)
• FLOW Connector for flow sensor
