24
Advanced Configuration
The advanced configuration mode also includes the parameters protected by password, that allow a complete configuration
of the system. This mode is normally accessed only by authorized technical personnel.
1) Once selected the “Advanced Configuration” option, press the
CAL button to edit the list of parameters, or press ESC to
return to the normal visualization mode.
2) Now use the ⇑ and ⇓ keys to scroll the list of the available
parameters.
3) To modify the displayed parameter, press CAL; to quit the mode press ESC.
List of Configuration Parameters
In this section are listed all the configuration parameters.
It is recommended to fill the last column with the values set for your application.
PAR. Description Min Value Max Value Default Value Set Value
P01 Functioning Type Pump 1 ON-OFF / Proportional ON-OFF
P02 Setpoint Pump 1
0.00 pH 14.00 pH 7.00 pH
P03 Hysteresis Pump 1 0.20 pH 2.00 pH 0.50 pH
P04 Dosage Pump 1 Acidification / Alkalinisation Acidification
P05
if P01= ON-OFF
if P01= Proportional
5%
30 sec
100%
360 sec
60%
60 sec
P06 Functioning Type Pump 2 ON-OFF / Proportional ON-OFF
P07 Setpoint Pump 2
0 mV 1000 mV 750 mV
P08 Hysteresis Pump 2 20 mV 200 mV 50 mV
P09 Dosage Pump 2 Chlorination / De-chlorination Chlorination
P10
if P06= ON-OFF
if P06= Proportional
5%
30 sec
100%
360 sec
60%
60 sec
P11 Alarm Pump 1 0 min 240 min 0 min
P12 Alarm Pump 2 0 min 240 min 0 min
P13 Start Delay 0 min 60 min 0 min
P14 Language
Italiano – English - Français - Español English
P15 Restore default values 0 255 0
P16 Password 0 255 0
P17 Alarm Functioning Relay NO / Relay NC Relay NO
P18 Flow Functioning Input NO / Input NC Input NO
P19 pH Equilibrium 0min 240min 0min
Warning! The complete list of parameters can be accessed only from the “Advanced Configuration” menu, while
the “Standard Configuration” mode allows to modify only the parameters that are not protected by password
(highlighted in bold in the table above).
PARAMETER 01 FUNCTIONING TYPE OF THE PUMP 1
This parameter allows to set the functioning type of pump 1, typically used for the pH control.
PARAMETER 02 SET-POINT PUMP 1
This parameter allows to enter the desired pH value for the swimming pool water. The dosing pump is activated / de-
activated to reach this value and keep it constant.
A
D
V
A
N
C
E
D
C
O
N
F
I G
.
C
A
L
>
Y
E
S
E
S
C
>
N
O
