58 9287500995 Rev B
If power is lost or communication is interrupted during transfer, the unit
will not recover and will no longer be operational.
Clicking the Start Transfer Data button displays the Settings File Saved? window (Figure 44
). Clicking
No in the Settings File Saved window will return the user to the BE2000E Embedded Program Loader
screen (Figure 43). Clicking Yes will display the Open Dialog box (Figure 45).
Figure 44. Settings File Saved Dialog Box
Figure 45. Open Dialog Box
Select the location of the embedded firmware update file, select the file, and click Open. The embedded
firmware will begin transferring from the PC to the BE2000E. A progress bar, as displayed in Figure 46
marks the progress of the transfer.
BESTCOMS™ Software BE2000E
